Hand-held Barcode Scanner
Standard configuration
operating system： Windows/iOS、Android/Linux
image sensor 、CMOS、pixel 640x480
Reading accuracy ≥3mil
Read depth of field
EAN13 (13mil) 55mm-300mm
QR CODE (15mil) 35mm-190mm
illumination： white LED
Overall size：16cm×9.5cm×7.1cm
Communication Interface： USB 2.0 TypeA Male
focus： Red LED 625nm Barcode Sensitivity
Tilt ±50° / Rotate 360° / Yaw ±50°
Field of view： Horizontal 45°, Vertical 34°
Power Adapter：Working voltage: DC5V±5%、Working current: <500mA
Symbol contrast：≥30%
Prompt way： buzzer, vibrator、LED prompt
working environment
Working temperature: -10℃~50℃
Storage temperature: -40℃~70℃
Relative humidity: 5%~95% (non-condensing)
Electrostatic protection: ±8kV (direct discharge)、±15kV (air discharge)
Drop height: 1.2 meters
code system
1D: Code128, UCC/EAN-128, AIM128, EAN-8, EAN-13, ISBN/ISSN, UPC-E, UPC-A, Interleaved 2 of 5, ITF-6, ITF-4, Matrix 2 of 5, Industrial 25, Standard 25, Code39, Codabar, Code 93, Code 11, Plessey, MSI-Plessey, RSS-14, RSS-Limited, RSS-Expand
2D: PDF417, QR Code, Data Matrix
Description
AWAKEN Scanner
Fast and accurate scanning that efficiently handles high-volume
payment processing.:Barcode /Payment Code
Supports: 1D/2D /Bar Codes
Fast Recognition: Exceptional Code
Identification: Dual Light 、Buzzer
Vibrating Alert： Shake-Proof &
Impact-Proof、Springback Key
Multiple System： Compatibility
Plug-and-Play
Multi-purpose, for all your needs.
Superior, both inside and outside.
Barcode、Payment Code
Quick scanning.
Adapts to various environments. Captures
1D/2D barcodes on screen and paper
even in poorly-lit environments.
Equipped with high-performance CMOS imaging
chip as well as white soft light and red light to fill
light and focus, the scanner can easily aim and
identify the code shown on the screen or printed
on the paper even in a poorly-lit environment.
High-Performance CMOS Imaging Chip
Accurate identification
assures rapid scanning
of exceptional codes.
Use a fast image decoding algorithm to read
distorted 1D/2D barcodes accurately.
With a fast image decoding algorithm, the scanner can accurately read
1D/2D codes even if they are contaminated, wrinkled, or distorted.
Vibrating alert for noisy environment.
In addition to the indicator light and buzzer,
a vibrating alert is also added to offer the staff haptic feedback on code scanning.
With this, no scan can be missed even in the nosiest environment.
The elegant but concise design
complements the décor taste of every store.
Good-Looking and Practical
Sleek streamlined scanner body.
The sleek streamlined body with silk-like tactile
interprets the elegance of the scanner vividly.
Vibrant surface design with
crescent-shaped ambient lights.
This sleek-looking scanner is sure to
add to the appeal of your shop decor.
Transparent handle with
an inbuilt cable.
Protected by the transparent handle, the
cable is prevented from damaging or detaching.
The trigger can withstand three million times presses.
